OS37-100-R-GMP紅外熱電偶 美國omega紅外熱電偶
可調范圍紅外熱電偶
OS37 & OS38 Series
2年保修 CE
IRThermocouples
OS37 & OS38 Series:Adjustable Range Infrared Thermocouples
OS37-10-J
10:1, 20:1 or 100:1 Optics Available
Built-in Air Purge
J or K Thermocouple Output Signal; R or S Type for 100:1 Models
Use With Standard Thermocouple Indicators and Controllers
Self-Powered
Temperature Compensated
Measurements to 2760°C (5000°F)
The OS37 Series infrared thermocouples for high emissivity targets (non-metals and coated metals) and OS38 series low emissivity units (clean metals) feature an internal
adjustment screw which adjusts the 2% accuracy band anywhere within the overall temperature range. Both OS37 and OS38 units offer a choice of 10:1, 20:1 or 100:1 optics.
All models have a built-in air purge collar that conveniently and efficiently maintains optical cleanliness in harsh environments.
Example of pricing for popular models is referenced in the "To Order" box. Use the "Part Number Builder" below to get pricing for all available models.
For complete product specifications see the detailed data sheet in the related section below.
產品型號 產品描述
OS37-10-J High emissivity sensor with 10:1 optics, type J thermocouple
OS37-10-J-GMP High emissivity sensor with 10:1 optics, type J thermocouple with subminiature low-noise thermocouple connector pair
OS37-20-J High emissivity sensor with 20:1 optics, type J thermocouple
OS37-10-K High emissivity sensor with 10:1 optics, type K thermocouple
OS37-20-K High emissivity sensor with 20:1 optics, type K thermocouple
OS38-20-J Low emissivity sensor with 20:1 optics, type J thermocouple
OS38-10-K Low emissivity sensor with 10:1 optics, type K thermocouple
OS38-20-K Low emissivity sensor with 20:1 optics, type K thermocouple
OS38-100-R Low emissivity sensor with 100:1 optics, type R thermocouple
產品型號說明
(1) (2) (3)
-
-
選項描述
(1) High or Low Emissivity Sensor
選擇
OS37 代表 High emissivity
OS38 代表 Low emissivity
(2) Field of View
選擇
10 代表 10 代表 1 optic
20 代表 20 代表 1 optic
100 代表 100 代表 1 optic
(3) Thermocouple Type
選擇
J 代表 Type J (for 10 代表 1 and 20 代表 1 optics only)
K 代表 Type K (for 10 代表 1 and 20 代表 1 optics only)
R 代表 Type R (for 100 代表 1optics only)
S 代表 Type S (for 100 代表 1optics only)
OS37-10-J
OS37-10-J-GMP
OS37-10-J-GST
OS37-10-K
OS37-10-K-20FT
OS37-10-K-GMP
OS37-10-K-GST
OS37-100-R
OS37-100-R-GMP
ATP-OS37-10-K-360
OS37-20-J
OS37-20-J-GMP
OS37-20-K
OS37-20-K-GMP
OS37-20-K-GST
OS38-20-J
OS38-20-K
OS38-20-K-GMP
OS38-20-K-GST
OS38-10-J
OS38-10-J-GST
OS38-10-K
OS38-10-K-GMP
OS38-10-K-GST
OS38-100-R
